Product Highlight
Plug & Play design with a pre-fitted UK plug for simple installation without special wiring.
4-zone induction hob with Bosch's fast and responsive heating technology.
Features PowerBoost for rapid boiling and QuickStart for automatic zone detection.
Intelligent Power Management ensures safe operation within a standard 13A socket's limits.
Modern frameless black glass design with easy-to-clean surface and TouchSelect Basic controls.
Specifications
| Specification | Description |
|---|---|
| Model Number | PUG61RAA5B |
| Type | Built-In Induction Hob |
| Installation | Plug & Play (13A Plug Included) |
| Zones | 4 Induction Zones |
| Controls | TouchSelect Basic |
| Max. Connected Load | 3.0 kW (13A) |
| Key Features | PowerBoost, QuickStart, ReStart, Power Management |
| Safety Features | Child Lock, Automatic Safety Shut-Off |
| Dimensions (W x D) | 592 x 522 mm |
Model Number
PUG61RAA5B
Usage Instruction
Install the hob in a suitable 60cm worktop cutout. Ensure adequate ventilation.
Simply plug the attached 13A plug into a standard, properly earthed wall socket.
Use induction-compatible cookware. The hob will activate zones automatically with QuickStart.
Use the touch controls to select zones and adjust power levels. Activate PowerBoost for faster boiling.
Wipe the glass surface with a damp cloth after it has completely cooled.
Safety Warning
The glass surface can retain residual heat after use. Use the residual heat indicator if present.
Do not use the hob if the glass is cracked. Disconnect from power immediately and contact service.
This appliance must be connected to an earthed socket. Do not use an extension lead.
The Power Management system may reduce power to other zones when multiple zones are used at high heat. This is normal operation.
Child Safety Instructions
Always activate the control panel Child Lock after use to prevent accidental activation.
Do not leave the appliance unattended while in use if children are present.
Country of Origin
Made in Germany
