Materials & Craftsmanship
The 18V STANLEY® FATMAX® V20 Cordless Circular Saw is designed with advanced battery technology, featuring a 2.0Ah Lithium Ion battery that boasts no memory effect and minimal self-discharge. This ensures reliable power and extended use between charges.
Product Features & Usage Scenarios
- Powerful Motor: Delivers up to 4,000rpm for efficient cutting performance.
- Adjustable Cutting Angles: Pivots up to 50° for versatile angled cuts.
- Dust Extraction Capability: Can be directly connected to the STANLEY® FATMAX® V20 wet & dry vacuum for efficient dust management.
- Safety and Convenience: Includes an electronic brake, spindle lock, and overload protection for safe and easy operation.
Dimensions & Specifications
| Specification | Description |
|---|---|
| Brand | Stanley FatMax |
| Battery Included | Yes |
| Bevel Stop Angles | 0-50° |
| Blade Change Method | With tool |
| Blade to Plate Edge | 25mm |
| Brake Type | Electronic |
| Charge Time | 2 hours |
| Charger Type | Standard charger |
| Colour | Black & yellow |
| Compatible Blade Diameter | 165mm |
| Disc Bore Size | 16mm |
| Dust Extraction Type | Dust vacuum facility |
| Grip Type | Over moulded |
| Height | 230mm |
| Length | 340mm |
| Maximum Bevel Left/Right | 50° |
| Maximum Cutting Capacity (45°) | 45mm |
| Maximum Cutting Capacity (90°) | 54mm |
| Motor Type | Replaceable carbon brushed |
| No Load Speed | 4000rpm |
| Number of Batteries Included | 1 |
| Number of Teeth | 24 |
| Overload Protection | Overload & overcurrent protection |
| Power Voltage Supply | Not mains fed |
| Spindle Lock | Yes |
| Standards | EN62841-1:2015, EN62841-2-5:2014, 2006/42/EC, 2014/30/EU, 2011/65/EU |
| Switch Type | Safety trigger switch |
| Tool Weight (with battery) | 3.4kg |
| Tool Weight (without battery) | 3kg |
| Vibration Emission (Sawing) | 1.6m/s² |
| Vibration Uncertainty (K factor) | 1.5m/s² |
| Width | 250mm |
| Product Code | 5035048738153 |
Installation & Maintenance
The saw includes a standard charger and a kit box for easy storage and transport. Regular maintenance includes checking the blade condition and ensuring the battery is charged. Follow all safety instructions for optimal use.
Warranty Details
Comes with a 1-year standard warranty, extendable to 3 years upon registration, providing assurance of quality and durability.
