Product Highlight
Compact 60 cm surface built for standard European cabinetry installation.
Four independent heating modules configured for varied cooking requirements.
Stable glass-ceramic panel engineered for consistent heat transfer and easy maintenance.
Precision control interface using digital capacitive keys with rapid power shift response.
Automatic safety suspension and residual-heat alert for project-grade compliance.
Factory-tuned power management supporting 9 load steps for efficient energy distribution.
Specifications：
| Brand | Ciarra |
| Model Number | CABBIH4-A |
| Product type | Built in Induction Hob |
| Voltage/Frequency | 220~240V/ 50-60HZ |
| Control Mode | Touch control |
| Total Power | 6000W |
| Cooking Zone | 4 |
| Suitable pan use refernece | 180mm Zone:140-260mm; 160mm Zone:120-200mm; |
| Power Setting | 9 power levels |
| Timer | Individual Timer |
| Timer Setting Range | 99 min |
| Safety Function | Child Lock,Residual Heat Indicator,Automatic Pan Detection,Automatic Safety Switch-off,Overheat Protection,Overflow Protection |
| Product dimensions(W*D*H) | 590*520*62mm |
| Cut-in dimensions(W*D) | 560*490mm |
| Rated Fuse | 32A |
| Warranty | 24months |
Usage Instruction
Place the hob on a flat, stable, and heat-resistant surface (or insert in a properly ventilated cabinet for built-in models).
Connect to a proper power source matching the voltage indicated.
Turn on the hob and select the desired heating zone and power level.
Place magnetic cookware on the selected heating zone.
Adjust the power level as needed during cooking.
After cooking, turn off the hob and unplug it.
Wait for the surface to cool completely before cleaning.
Clean with a soft, damp cloth. Avoid abrasive cleaners.
