| Power cable length | 0.12 m |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| Maximum digital resolution | 3840 x 2160 pixels |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| Ethernet LAN | Yes |
| Product colour | Silver |
| High Dynamic Range (HDR) supported | Yes |
| Card reader integrated | No |
| DisplayPorts quantity | 1 |
| Mac operating systems supported | Yes |
| Power supply | 90 W |
| Harmonized System (HS) code | 84733020 |
| Linux operating systems supported | Yes |
| Connectivity technology | Wired |
| HDMI ports quantity | 1 |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11 |
| Microphone in | No |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI version | 2.0 |
| Brand compatibility | Dell |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Plug and Play | Yes |
| Quantity per pack | 1 pc(s) |
| Height | 24.5 mm |
| Width | 69.8 mm |
| Depth | 69.8 mm |
| Weight | 83.9 g |
Usage Instruction
Ensure the host device (laptop, tablet) supports USB-C with DisplayPort Alt Mode and Power Delivery.
Connect the adapter to your host device using the attached 12cm USB-C cable.
Connect external displays, Ethernet, and USB devices to the adapter before or after connecting to the host. For best results, connect all peripherals first.
The adapter can deliver up to 90W of power to your host device via the upstream USB-C port. Use a compatible USB-C power supply (not included) for charging.
The HDMI (v2.0) and DisplayPort outputs support resolutions up to 4K @ 60Hz. They cannot be used simultaneously for extended desktop mode; they are designed for display mirroring.
The two USB-A 3.2 Gen 2 ports support high-speed data transfer for external storage and peripherals.
Safety Warning
Do not use the adapter if the cable or housing is damaged.
Use only with the provided 12cm USB-C cable. Using a longer or incompatible extension cable may result in performance loss or connection issues.
Ensure adequate ventilation around the adapter during use. Do not cover it or use it in high-temperature environments.
The 90W power delivery is for charging compatible host devices. Verify your device's power requirements before use.
This product is intended for connection to IT equipment. Do not connect it to mains power or non-specified industrial equipment.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
Country of Origin
Made in China
